Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: HUAERTAI
  • Model Number: PVDF
  • Usage: Outdoor
  • Function: Anti-Static, Antibacterial, Fireproof, Mould-Proof
  • Surface Treatment: Anodized, Brushed, Foil Decoration, Mirror, PE Coated, Printing, PVDF Coated
  • Color: according your specific requirement
  • Standard Size: 1220*2440*4mm
  • Port of loading:: Shenzhen China
  • thickness of the Alu foil:: 0.15mm-0.5mm
  • maxi width:: 1570mm
  • thickness of the board:: 3-10mm
  • certificate:: CE, SGS , ISO9001, BV,China well-know trademark
  • Delivery Detail:: 10 days after receiving 30% deposit
  • Quality Garantee:: 10-15 years
  • Aluminum alloy:: 1100 or 3003

Packaging & Delivery

Packaging Details wooden case or in bulk. A 20 feet container can hold 1600 pieces of the 1220*2440mm.
Delivery Time within 10 days after receving 30% deposit

                   Item Name:Color coated good price aluminum cladding manufacturer

PRODUCT  DETAILS

  • Applications:

    1.Buildings outer-wall, curtain wall.

    2.Redecoration of old buildings outer-wall.

    3.Balconies, installation units,indoor partitions .

    4.Signboard

    5. Inner-wall decorating panel, ceilings, advertisement signboard

    6.Industrial usage, vehicle bodies

  • Structure:

        Color coated good price aluminum cladding manufacturer



 4mm PVDF PPG coating  aluminium plastic composite panel

  • Advantage:   Color coated good price aluminum cladding manufacturer



  • Specifications:

panel thickness

3mm, 4mm, 5mm, 6mm

aluminum thickness

0.1mm to 0.6mm (below the 0.1mm belong to the special size)

Standard width

1220mm

standard length

2440mm

special width

1500mm, 1550mm(part of 4mm panels' width can reach 1250mm)

special length

customization (the maximal length is 6 meters)



COLOR   CHART

Color coated good price aluminum cladding manufacturer

    Notice:

  1. Painting of acp aluminum composite panel is supplied by PPG, Becker

  2. choose the color from the above color card of acp aluminum composite panel.

    Also, any Pantone colors or Ral colors can be customized

  3.  Pe coating of acp aluminum composite panel lasts for 8 to 10 years.

  4.  PVDF coating of acp aluminum composite panel lasts for 15 to 20 years.

TEST  REPORT

  • Test Report of Physical Performance



1. Appearance quality

NO.

Test item

Standard index

Test value

Single item determination

  1

Vestige

Indistinct

Indistinct

Eligible

  2

Coating omit

Not allowed

No

Eligible

  3

Ripples

Not allowed

No

Eligible

  4

Rubbles

Not allowed

No

Eligible

  5

Flaw(3mm)

≤3/m2

3/m2

Eligible

  6

Scratch

Not allowed

No

Eligible

  7

Abrasion

Not allowed

No

Eligible

8

Aberration

Indistinct

Indistinct

Eligible

2. Dimensions deviation

NO.

Test item

Standard index

Test value

Single item determination

  1

Length

±3mm

0.0mm±1.2mm

Eligible

  2

Width

±2mm

0.0mm±1.0mm

Eligible

  3

Thickness

±0.2mm

±0.02mm±0.08mm

Eligible

  4

Squareness

≤5mm

1.1 mm

Eligible

  5

Edge unstrightness

≤1mm/m

0.4 mm/m

Eligible

  6

Warpage

≤5mm/m

2.1 mm/m

Eligible

  • Test Report of Coating Specific Performances



NO.

 Test item

Standard index

Test value

Single item   determination

  1

Coating Thickness

Min23μm  Average25μm

Min26μm Average27μm

Eligible

  2

Gloss Tolerance

 ≤10

Gloss

Eligible

  3

Surface Pencil Hardness

 ≥HB

2H

Eligible

  4

Coating Adhesive

 ≤2T

2T

Eligible

  5

Coating Adhesive

 Not Lower Than Class1

Class1

Eligible

  6

Impact Resistance

 ≥50kgNaN, No Crack No Depainting

50kgNaN, No Crack No   Depainting

Eligible

  7

Grinding Resistance

 ≥5L/μm

6.4L/μm

Eligible

  8

Boiling Water Resistance

 No Change

No Change

Eligible

  9

Pullute Resistance

 ≤15%

4.4%

Eligible

 10

Hydrocheoric

No Change

No Change

Eligible

 11

Alkaline Resistance

No abnormity ΔE2

No abnormity ΔE=0.4

Eligible

 12

Nitric acid resistance

No abnormity ΔE=5

No abnormity ΔE=3.73

Eligible

 13

Oil rosistance

No Change

No Change

Eligible

 14

Solvent Resistance

No base exposed

No base exposed

Eligible

 15Solvent ResistanceNo ChangeNo ChangeEligible
 16Scrub ResisitanceNo Change   ≥10000 timesNo Change   ≥10000 timesEligible

CERTIFICATE



PACKAGE

PROJECT CASE







EXHIBITIONS



FACTORY





COMPANY INFORMATION

  • Company Basic Information

Production Lines

6 lines

Factory Size

47000 square meters square meters

Monthly Capacity

480,000 square meters

Investment on Manufacturing Equipments

US$1 Million - US$2.5 Million

No. of Staffs

101 - 500 People

No. of R/D Staffs

11 - 20 People

No. of Engineers

5 - 10 People

No. of QC Staffs

5 - 10 People

  • Company Overview  huaertai aluminum composite panel

  •  Testing Center



  • Company culture

Why Choose Us?
Color coated good price aluminum cladding manufacturer
  • we are a professional manufacturer of aluminium composite panel for 20 years.

  • we haveour own brand of aluminium composite panel, "Huaertai",which has been  widely   acknowledged by customers at home and broad and has received many reputations,   such as "China Top Brand", "China Well-known Trademark",etc

  • We have six production lines of alucobond panels and have high production capacity so that we can ensure fast delivery time.

  • your needs or inquires will get our immediate attention.

Contact Information:

Dongguan  Walltes Decorative Material Co.,LTD

Contact: Sherry
Tel:  (86)769-22716318                 Mobile:  13539856383
Fax: (86)769-89026199                 Skype:   sherry3642
QQ:  478427817                             Website:  http://www.huaertai.com
ADD:No.6 Huaertai Rode,Xinhe Chuangye Development Zone,
          Wanjiang District,Guangdong,P.R.Chin


          Quality Shapes Future!

Warmly Welome to Visit Our Factory!
