Signboard interiorACP Aluminium Composite Panel

FOB Reference Price:Get Latest Price
US $6.5-12 / Square Meter | 600 Square Meter/Square Meters (Min. Order)
Supply Ability:
3800000 Square Meter/Square Meters per Year
Port:
SHENZHEN
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
HUAERTAI
Model Number:
HUAERTAI Plus PVDF
Usage:
Outdoor
Function:
Fireproof, Mould-Proof
Surface Treatment:
Brushed, Mirror, PE Coated, PVDF Coated
Standard Size:
1220*2440*4mm
Other Color&Size:
Available
Port of loading::
Shenzhen China
surface coating::
PET and PVDF
thickness of the Alu ::
0.15mm-0.6mm
maxi width::
2000mm
thickness of the board::
3mm-10mm
certificate::
CE, SGS , ISO9001, BV,China well-know trademark......
Delivery Time::
15 days after receiving 30% deposit
Packaging Detail::
in bulk or wood case/ iron case
Packaging & Delivery
Packaging Details
in bulk/ metallic cases/ wooden crate
Delivery Time
Shipped in 15 days after payment

                         Item Name:Signboard interior ACP Aluminium Composite Panel

PRODUCT  DETAILS

  • Applications:

    1.Buildings outer-wall, curtain wall.

    2.Redecoration of old buildings outer-wall.

    3.Balconies, installation units,indoor partitions .

    4.Signboard

    5.Inner-wall decorating panel, ceilings, advertisement signboard



FACTORY

  • Structure & Advantage:



  • Specifications:

panel thickness

3mm, 4mm, 5mm, 6mm

aluminum thickness

0.1mm to 0.6mm

Standard size

1220*2440mm

special width

1250mm, 1500mm,1550mm,1570mm

special length

customization (the maximal length is 6 meters)

COLOR   CHART

Signboard interior ACP Aluminium Composite Panel

    Notice:

  1. Painting of acp aluminum composite panel is supplied by PPG, Becker

  2. choose the color from the above color card of acp aluminum composite panel.

    Also, any Pantone colors or Ral colors can be customized

  3.  Pe coating of acp aluminum composite panel lasts for 10 years.

  4.  PVDF coating of acp aluminum composite panel lasts for 15 to 20 years.

TEST  REPORT

 Test Report of Physical Performance

1. Appearance quality

NO.

Test item

Standard index

Test value

Single item determination

  1

Vestige

Indistinct

Indistinct

Eligible

  2

Coating omit

Not allowed

No

Eligible

  3

Ripples

Not allowed

No

Eligible

  4

Rubbles

Not allowed

No

Eligible

  5

Flaw(3mm)

≤3/m2

3/m2

Eligible

  6

Scratch

Not allowed

No

Eligible

  7

Abrasion

Not allowed

No

Eligible

8

Aberration

Indistinct

Indistinct

Eligible

2. Dimensions deviation

NO.

Test item

Standard index

Test value

Single item determination

  1

Length

±3mm

0.0mm±1.2mm

Eligible

  2

Width

±2mm

0.0mm±1.0mm

Eligible

  3

Thickness

±0.2mm

±0.02mm±0.08mm

Eligible

  4

Squareness

≤5mm

1.1 mm

Eligible

  5

Edge unstrightness

≤1mm/m

0.4 mm/m

Eligible

  6

Warpage

≤5mm/m

2.1 mm/m

Eligible



 Test Report of Coating Specific Performances

NO.

 Test item

Standard index

Test value

Single item   determination

  1

Coating Thickness

Min23μm  Average25μm

Min26μm Average27μm

Eligible

  2

Gloss Tolerance

 ≤10

Gloss

Eligible

  3

Surface Pencil Hardness

 ≥HB

2H

Eligible

  4

Coating Adhesive

 ≤2T

2T

Eligible

  5

Coating Adhesive

 Not Lower Than Class1

Class1

Eligible

  6

Impact Resistance

 ≥50kgNaN, No Crack No Depainting

50kgNaN, No Crack No   Depainting

Eligible

  7

Grinding Resistance

 ≥5L/μm

6.4L/μm

Eligible

  8

Boiling Water Resistance

 No Change

No Change

Eligible

  9

Pullute Resistance

 ≤15%

4.4%

Eligible

 10

Hydrocheoric

No Change

No Change

Eligible

 11

Alkaline Resistance

No abnormity ΔE2

No abnormity ΔE=0.4

Eligible

 12

Nitric acid resistance

No abnormity ΔE=5

No abnormity ΔE=3.73

Eligible

 13

Oil rosistance

No Change

No Change

Eligible

 14

Solvent Resistance

No base exposed

No base exposed

Eligible

CERTIFICATE



PACKAGE    Signboard interiorACP Aluminium Composite Panel

PROJECT CASE

EXHIBITIONS







COMPANY INFORMATION

  • Company Basic Information

Production Lines

6 lines

Factory Size

47000 square meters square meters

Monthly Capacity

480,000 square meters

Investment on Manufacturing Equipments

US$1 Million - US$2.5 Million

No. of Staffs

101 - 500 People

No. of R/D Staffs

11 - 20 People

No. of Engineers

5 - 10 People

No. of QC Staffs

5 - 10 People

  • Company Overview

  •  Testing Center  2016 building material width 1570mm Aluminium Composite Panel



  • Company culture

Why Choose Us?
        Signboard interiorACP Aluminium Composite Panel
  • we are a professional manufacturer of aluminium composite panel for 30 years.

  • we have our own brand of aluminium composite panel, "Huaertai",which has been  widely acknowledged by customers and has received many reputations,

    such as "China Top Brand", "China Well-known Trademark",etc.

  • We have six production lines of alucobond panels and have high production capacity so that we can ensure fast delivery time.

  • your needs or inquires will get our immediate attention.
